ROUTER REYEE EW1200G-PRO WiFi5 AC1300 4x 10/100/1000

Router Reyee WiFi5 RG-EW1200G-PRO AC1300 wave2 (4x Giga)

SKU: RED-RG-EW1200G-PRO Categoría:

Descripción

Port Specifications
LAN ports 4 x 10/100/1000BASE-T
Number of LAN ports 3 x 10/100/1000BASE-T
WAN ports 1 x 10/100/1000BASE-T
System Specifications
RAM 128 Mb
Wi-Fi Radio
Operating band IEEE 802.11b/g/n，2.400GHz~2.4835GHz
IEEE 802.11a/n/ac，5.150GHz～5.350GHz
IEEE 802.11a/n/ac，5.470GHz～5.725GH
IEEE 802.11a/n/ac，5.725GHz～5.850GHz
FEM EPA
Max. Wi-Fi Speed 2.4 GHz, 400 Mbps
5 GHz, 867 Mbps
MIMO 2.4 GHz, 2 x 2
5 GHz, 2 x 2
Wi-Fi standard Wi-Fi 5 (IEEE 802.11ac)
Antenna
Antenna 6 x external antennas
Antenna gain (2.4 GHz) 4.5 dBi
Antenna gain (5 GHz) 6.0 dBi
Software Specifications
Ruijie Cloud management Yes
Reyee Mesh 3.0 Yes
System Performance Capacity
Maximum number of concurrent clients 2.4 GHz: 64
5 GHz: 128
Recommended number of concurrent clients 2.4 GHz: 16
5 GHz: 64
Dimensions and Weight
Product dimensions (W x D x H) 220 mm × 140 mm × 36 mm
Weigh 0.390 kg
Certification and Regulatory Compliance
Certification CE, CB
Basic Configurations
Internet access mode PPPoE, DHCP, Static IP, WISP, L2TP
Preconfiguration Si
Reset and keep configurations Si
Restoring factory defaults Si
Configuration backup Si
Local upgrade Si
Online upgrade Si
Scheduled upgrade No
AP mode Si
Ethernet Switching
WAN port aggregation No
LAN port aggregation No
Specifying the VLAN tag Si
IP Service
Port mapping Si
ARP binding Si
Number of ARP binding entries 64
DDNS Si
No-IP DNS Si
Ruijie DDNS Si
NAT-DMZ Si
Number of port mapping entries 50
UPnP Si
IPv6 Si
Behavior Management
Parental control Si
Client access control (based on MAC addresses) Si
Client access control (based on time) Si
Maximum number of controlled clients 32
Maximum number of parental control policies No
Selecting clients from the client list to block their access to the Internet Si
Specifying MAC addresses of controlled clients Si
Ethernet Interface
MAC address cloning Si
VLAN-based IPTV Si
Flow Control
Flow control based on number of users Si
Standalone/Shared mode Si
Interface flow control Si
IPTV/VLAN
Multiple IPTV ports Si
Multicast
IGMP proxy Si
IGMP snooping No
Network Management and Monitoring
Line detection Si
Ruijie Cloud management Si
Scheduled device restart Si
Wired / Wireless repeater mode Si / Si
WISP mode Si
Rate Limiting
Client-based rate limiting Si
Reyee Mesh 3.0
Reyee Mesh 3.0 Si
Automatic switching between wired and wireless repeater mode Si
Recommended hop count 2
Maximum number of clients 192
Maximum number of devices 32
Security
Encryption mode Si
System Performance Capacity
Maximum number of concurrent clients 2,4 GHz: 32
5 GHz: 64
Recommended number of concurrent clients 2,4 GHz: 8
5 GHz: 24
IPTV/IGMP client capacity 5
IPTV/IGMP multicast capacity 5
PTV/IGMP wired forwarding performance 20 Mbps
Recommended camera limit 2,4 GHz: 6
5 GHz: 16
VPN
Number of concurrent tunnels supported by the OpenVPN server 8
Certificate authentication Si
OpenVPN bandwidth 13 Mbps
OpenVPN client Si
OpenVPN server Si
Server domain name configuration Si
Username and password authentication Si
Number of concurrent tunnels supported by the PPTP VPN server No
PPTP VPN client Si
PPTP VPN server No
Wireless Configuration
Guest Wi-F Si
WLAN
1024-QAM No
MLO No
DFS Si
802.11k/v roaming Si
Fi blocklist capacity 30
SSID hiding Si
