ASUS PRIME B760M-A-D4-CSM

PLACA 1700 MICRO-ATX ASUS B760M-A-D4-CSM 4xDDR4 / HDMI / USB3.2

PLACA ASUS PRIME B760M-A-D4-CSM/ MICRO ATX / SOCKET 1700 / 4xDDR4 / DP / 2xHDMI / USB3.2. Para procesadores Gen12 y Gen13.

SKU: ASUS-B760M-A/D4/CSM Categoría:

Descripción

Factor de FormaMicro ATX
ChipsetIntel B760
CPU Soportados
Intel Socket 1700 para 13ª Generación de procesadores Core
y 12ª Generación de procesadores Core, Pentium Gold
y Celeron
Memoria
4x DIMM, Max. 128Gb
5333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)
4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)
3333(OC)/3200/3000/2933/2800/2666/2400/2133
Non-ECC, Un-buffered
Dual Channel
Intel XMP
OptiMem II
Slots Expansion
1 x PCIe 4.0 x16 slot
1 x PCIe 4.0 x16 slot (supports x4 mode)
1 x PCIe 4.0 x16 slot (supports x1 mode)
Graficos1 x DisplayPort
2 x HDMI
Conectores Internos E/S1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
2 x 4-pin Chassis Fan headers
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
3 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x LPT header
1 x S/PDIF Out header
1 x SPI TPM header (14-1pin)
1 x 20-3 pin System Panel header with Chassis intrude function
Panel E/S Trasero2 x USB 3.2 Gen 2 ports (2 x Type-A )
4 x USB 2.0 ports (4 x Type-A)
1 x DisplayPort
2 x HDMI® ports
1 x Realtek 2.5Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port
AudioRealtek 7.1 Surround Sound High Definition Audio CODEC
LAN
1 x Realtek 2.5Gb Ethernet
Almacenamiento
2 x M.2 slot (Key M), type 2242/2260/2280 (PCIe 4.0 x4)
4 x SATA 6Gb/s Intel Rapid Storage RAID 0/1/5/10
USB
Traseros: 2 x USB 3.2 Gen 2 ports (2 x Type-A ); 4 x USB 2.0 ports (4 x Type-A)
Delanteros: 2x USB 3.2 Gen1 (total 4 puertos); 1x USB 3.2 Gen1 (soporta Tipo-C); 2x USB 2.0 (total 4 puertos); 1x USB 2.0

Información adicional

*Formato Placa

Mini-ATX

*Tipo de Memoria

DIMM DDR4

*Zócalo

Intel 1700
