BRIDGE REYEE RG-EST310 V2
BRIDGE REYEE RG-EST310 V2

BRIDGE EXTERIORES REYEE EST310 V2 WIFI 5GHz ALCANCE 1KM

Bridge exteriores Reyee RG-EST310 V2 WIFI AC 5GHz 867Mbps alcance 1Km/2Km 10dBi

SKU: RED-RG-EST310/V2 Categoría:

Descripción

Product Category
Product Category No
Port Specifications
Total number of RJ45 ports 1
Total number of optical ports 0
Number of 1GE combo ports 0
Number of 1GE SFP ports 0
Number of 10/100BASE-T ports 1
System Specifications
Flash memory No
Forwarding rate No
Switching capacity No
Power Supply and Consumption
Number of PoE Out ports 0
Number of PoE/PoE+ Out ports 0
Power Supply 24 W passive PoE
PoE standard No (Passive PoE)
Dimensions and Weight
Product dimensions (W x D x H) 147 mm x 76 mm x 37 mm
Weigh 0.350 kg
Certification and Regulatory Compliance
EMC No
Safety compliance & Certification CE
Hardware Features
Radio Design 5 GHz single-band dual-stream
2.4 GHz Band No
5 GHz Band Si
Protocol and Standard 802.11ac/n/a
Wi-Fi 4/5/6/7 Wi-Fi 5
Spatial Streams Two spatial streams, 2×2, MIMO
5G Channel Width Auto/20/40/80 MHz
Receiver Sensitivity 11a: -89 dBm (6 Mbps), -80 dBm (24Mbps), -76 dBm (36 Mbps), -71 dBm (54 Mbps)
11n: -83 dBm@MCS0, -65 dBm@MCS7, -83 dBm@MCS8, -65 dBm@MCS15; 11ac: -86 dBm (MCS0), -63 dBm (MCS9)
Nominal Receive Sensitivity @20 MHz: 91dBm (MCS0) TO -57dBm (MCS9)
@40 MHz: -83dBm (MCS0) TO -57dBm (MCS9)
@80 MHz: -76dBm (MCS0) TO -51dBm (MCS9)
Modulation Levels (Adaptive) MCSO(BPSK) to MCS9 (256QAM)
Wi-Fi Protocols (5 GHz) Wi-Fi 5 (IEEE 802.11ac)
Wireless Data Rate 867 Mbps
5G: 867 Mbps
Frequency Bands 5 GHz: 802.11a/n/ac: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz
Note: Country-specific restrictions apply.
5 GHz Max. Transmit Power 26 dBm
Surge Protection Common mode: ±4 kV
Differential mode: ±2 KV
2.4 GHz Antenna Gain No
5 GHz Antenna Gain 10 dBi
IP Rating IP54
Working Distance 1 Km
Bridging Performance 90 Mbps/100 meters (HT40)
80 Mbps/500 meters (HT40)
80 Mbps/1 km (HT40)
40 Mbps/2 km (HT40)
RSSI (dBm) –52 dBm/100 m
–65 dBm/500 m
–68 dBm/1 km
–75 dBm/2 km
Management Radio 5.150～5.350GHz，5.725～5.850GHz
ESD Protection Tolerance:±8 kv Contact/ ±15 kv Air
Software Features
Operating Mode Base Station/CPE
Channel Spacing 20 MHz
TDMA Fixed Mode/Flexible Mode
WLAN Security WPA2-PSK
Management SSID @Ruijie-bxxxx
SSID Hiding Si
Spectrum Scan Si
Antenna Aligment Si
One-Touch Pairing No
WMM Si
Storm Control Si
VLAN Packet Transmit Si
DHCP Server Si
DHCP Client Si
Network Diagnostics Ping/TraceRoute/Dns
Cloud Management Si
Power Configuration Si
Country/Region Code Si
Remote Restart Si
SON Self-organizing Networking with Bridges
SNMP Si
Link Aggregation No
Ping Si
Traceroute Si
AI Heatmap Si
Package Contents
Wireless Bridge/Antenna 2
PoE Injector 2
DC Power Adapter No
Mounting Bracket 2
